Automatic Shrink Wrapping Machine - 120 to 200 BPM Multi Track
Our Automatic Shrink Wrapping Machines create tight, durable bundles for bottles, cans and multipacks, ready for transport and retail display. Built for continuous operation, they reduce manual handling, save packing time and improve overall line throughput.
Features and Specifications
- Heavy duty chains with pins for conveyor assembly.
- Digital temperature controller with sensor to control the chamber temperature
- With PID controller system
- Heavy duty gear box with the motor
- Separate indicator for input lines, blower, cooling fan, and motor
- Interlocking system between the controls for safety reasons
- Aluminum heat resistant coating for the hot air chamber
Specifications
| Power Supply | 415 V Three Phase |
|---|---|
| Power Consumption | 13 KW & 17 KW |
| Control System | PLC Control System with HML |
| Range |
Minimum: 4 to 6 Maximum: 6 to 12 |
| Production Capacity |
300 ml bottle → 5 x 7 = 35 Bottles 500 ml bottle → 6 x 4 = 24 Bottles 1000 ml bottle → 4 x 3 = 12 Bottles 2000 ml bottle → 3 x 3 = 9 Bottles |
| Packing Material | L.D. Film, 80–90 micron thickness, 520 mm & 580 mm |
| Applications | Mineral Water, Juice and Beverage Bottles etc. |
